MSN2700-CS2RC, NVIDIA® Mellanox Spectrum Based 32-Port Ethernet L3 Data Center Switch, 32 x 100Gb QSFP28, Cumulus Linux™, C2P Airflow
N5860-48SC is a high density switch in a compact 1U form factor with full line rate 48 1/10GbE and 8 40/100GbE ports. It adopts Broadcom chips to deliver 1.28 Tbps switching capacity and 1920 Mpps forwarding rate.
Technical Specifications
Deep dive into the specifications and performance metrics.
| Feature | Value |
|---|---|
| Manufacturer | Mellanox |
| Jumbo Frames | 9,216 |
| Ports | 32x 100G QSFP28 |
| CPU | Dual-corex 86 |
| Max. 100GbE Ports | 32 |
| Switching Capacity | 6.4 Tb/s |
| Max. 50GbE Ports | 64 |
| Packet Buffer | 16MB |
| Max. 40GbE Ports | 32 |
| Airflow | Front-to-Back |
| Max. 25GbE Ports | 64 |
| System Memory | 8GB |
| Max. 10GbE Ports | 64 |
| Forwarding Rate | 4.76 Bpps |
| Latency | 300ns |
| SSD Memory | 32GB |
| MAC Address | 256K |
| Typical Power (ATIS) | 150W |
| Power Supply | 2 (1+1 Redundancy) Hot-swappable |
| Fan Number | 4 (N+1 Redundancy) Hot-swappable |
| Dimensions (HxWxD) | 1.72"x 16.84"x 27" (43.8x 427.8x 686mm) |
| Weight | 11.1kg (24.5lb)
|
